              20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration
              • 20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration
              • 20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration
              • 20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration
              • 20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration

              20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration

              Company ProfileHangzhou Darlly Filtration Equipment Co.,ltd is a high-tech company located in Fuyang, Hangzhou,Zhejiang Province, China. Darlly specialiazes in designing and manufacturing various filter cartridges used for diiferent applications.Our filter cartridges are widely used in Bio-pharmaceu......

              Send Inquiry

              Product Description

              Company Profile
              20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration

              Hangzhou Darlly Filtration Equipment Co.,ltd is a high-tech company located in Fuyang, Hangzhou,Zhejiang Province, China. Darlly specialiazes in designing and manufacturing various filter cartridges used for diiferent applications.
              Our filter cartridges are widely used in Bio-pharmaceuticals, Microelectronics,Food and beverage, Power generation,Petrochemical, Metal processing,Drinking water treatment,Swimming pools and spa water treatment, Mechanical manufacturing,Mining,etc markets.We have the market share all over the world, most of the products sell to North America, Europe,Southeast Asia,Middle east,Taiwan and all the area in China.With 14,727 square meters of factory area and 32,000 square meters of building area, state-of-art facility, manufaturing and testing equipment, professional R&D team. Darlly is well accepted in the global market.We have hundreds of "off-the-shelf" products for you to choose. Whatever you cannot find in our catalog,we can make it for you. Define your needs and let us put your vast resources to work for you, give us the opportunity to go beyond the expected, and you will see what a difference Darlly can make.
              When our customers succeed, Darlly succeeds. To make our customers stronger and to grow with customers is our mission."Endevored to produce the best cartridges" is our continously pursued goal. Our commitment is to continously enhance our ability to innovate, and supply quality products, resonable price and excellent service to meet the diverse and demanding requirements from our customers.
              Product Details

              1.Media: Polypropylene, Glass Fiber;
              2.Support/Drainage: PP

              General Description:

              --------------------------------------


              MHF Series Filter Cartridge is a new product developed by Darlly Filtration Equipment Co.,Ltd in Hangzhou China. This cartridge is designed to be used in different filter housings which contains 1 to 37 filter cartridges. It can be used for a variety of hardwares and for different flow rate request. The large diameter with big filter area insures to reduce the number of filter cartridges and the dimension of housing required.



              Applications:-- Prefiltration of RO, Pretreatment of sea water desalination

              -- Condensate water filtration, hot water recovery in power generation
              -- API, solvents, and water filtration in BioPharm market
              -- The filtration of bottled water, high Fructose, edible oil, soft drinks,and milk
              -- Paints and coatings, Petrochemical, Refineries
              -- Microelectronics, film, fiber and resin



              Features:

              _____________________________________________________________________



              -- High dirt holding capacity, longer service life
              -- Less cartridge change out to save the labor cost
              -- O-ring design cause no bypass to ensure the filtration efficiency
              -- Easy handing result in less manpower
              -- Wide chemical compatability for different applications



              Part numbers/Ordering information


              Darlly Multi-high flowment filter cartridge P/N :

              DLMHF*-=-#-+(e.g.,DLMHF-5-PP-F-A)


              Code *Removal RatingCode=Media Type
              11um PPPolypropylene
              33umGFPleated glass fiber
              55um
              1010um
              2020um
              5050um
              7070um



              Code # Seal Material
              EEPDM
              FE-FKM
              Code+End Cap Type
              ACode A
              BCode B
              20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration

              Certificate

              20um High Flowment Glass Fiber Filter Cartridge for Water Filtration Pre Filtration

              Outside Diameter:6.5 inch(165mm)
              Length:  39 inch(1000mm)
              Filter media:Polypropylene (PP),Glass Fiber
              Support/Drainage and  End caps  :Polypropylene (PP)
              End Cap Material : Glass Fiber reinforced Polypropylene (PP)
              Seal Material :EPDM, FEP encapculated Viton
              Removal Rating:  1, 3, 5, 10, 20, 50, 70µm
              Maximum Operating Temperature: 80°C
              Maximum Differential Pressure:3.4Bar,80°C
              Recommended Change out Differential Pressure:2.4Bar,20°C.
              Suggested maximum flow rate: 1300LPM
