Product Description

China HYDAC medium pressure filter housing LF-0060X5 for high performance cleaning equipment

We can manufacture filter as your requirement .Please kindly advise photo and size . Welcome OEM & ODM !Kindly inform us following information
1,Photo
2,ID,OD,Height
3,Filtration Precision
4,End Cap

1.INTRODUCTION

Filter of Germany Hydac LF160 adopt advanced anti-corrosion and high-efficiency ultra-fine fiber condensing material as the filter main body. The filter element of the system consists of pre-filter layer, ultra-fine fiber layer, support layer, filter layer and gravity sedimentation layer. The solid particles in the output air of the compressor can be filtered out to a maximum of 3μm, while the tiny water-dissolved gas of about 0.01-1μm is condensed into larger oil droplets when passing through the filter element, accumulates at the bottom of the filter element, and passes through. The return pipe siphon at the bottom of the filter element is siphoned back to the lubrication system so that the compressor discharges purer, oil-free compressed air.

2.TECHNICAL DATA

1) Work Pressure:100Bar
2) Temperature:-10ºC--+100ºC
3) Housing Material:Aluminum
4) Connection:Screw Thread
5) Indicator:Visual Differential Indicator

3.INSTALLATION SIZE

Model	B1	B2	B3	B4	D1	D2	D3	D4	H1	H2	H3	T1	T2	SW
HLF30	69	36	45	30	67	52	G1/2	M5	137	31	75	15	8	24
HLF60	90	48	56	32	84	68	G3/4	M6	137	39	75	17	9	27
HLF110									206
HLF140									247
HLF160	125	65	85	35	116	95	G11/4	M10	204	46	95	21	14	32
HLF240									262
HLF330	159	85	115	60	160	130	G11/2	M12	255	52	105	23	17	36
HLF660									422

How to work?

The filter, also known as the decontaminator and the filter valve, is an indispensable device for the transmission medium piping system. Its function is to filter the mechanical impurities in the medium, protect the fittings on the pipeline from wear and blockage, and protect the equipment from normal work. When the fluid enters the filter cartridge of a certain type of filter, the impurities are blocked, and the clean tourism is discharged from the filter outlet. When it needs to be cleaned, the removable filter cartridge can be removed and reinstalled after processing. Therefore, it is easy to use and maintain

Packaging & Shipping

1.Carton inside,wooden outside,neutral packaging

2.As your requirements

3.Shipment port:Shanghai or any other chinese ports

4.By international express,air and sea
China HYDAC medium pressure filter housing LF-0060X5 for high performance cleaning equipment

Company Information

Xinxiang City Huahang Filter Co., Ltd. is a professional industrial filter manufacturer integrating design, production and marketing. With strong technical force, perfect testing means, and excellent aftersales service,we provide users with a variety of highquality products Our main products include hydraulic filters, air filters and pipe filters. Products are widely used in petroleum, chemical and metallurgical machinery, textile, pharmaceutical,automobile, chemical fiber, and air-conditioning.
China HYDAC medium pressure filter housing LF-0060X5 for high performance cleaning equipment

ALTERNATIVE HYDAC LF160 PRESSURE LINE FILTER SERIES
