China Chunke Portable 0.5t Salt Water Softener for Water Treatment

Product Description

CHUNKE Portable 0.5t Salt Water Softener for Water Treatment

Water softener filter
Ion exchange resin is used in water softening system for Ca+, Mg+ and other cation exchange. To prevent undissolved salt from depositing in the surface of reverse osmosis membrane, the resin which ensures well permeable ability of membrane module after it works a long time and extends lifetime of membranes, enhances quality stability of ro purified water. Water softener is vertical structure which use frp material, produced as vessel standard, designed pressure for 8kg/cm2 that American auto valve is used for full-automatic salt regeneration.

Model and details

Model	Productivity	Resin tank	Resin loading quantity	Brine tank size	Pipe size
CK-SF-500L	0.5T	844	30kg	25L	3/4''
CK-SF-1000L	1	1054	50kg	60L	3/4''
CK-SF-2000L	2	1252	80kg	60L	G1''
CK-SF-3000L	3	1465	100kg	100L	G1''
CK-SF-4000L	4	1665	150kg	200L	G1 1/4''
CK-SF-5000L	5	2072	200kg	200L	G1 1/4''
CK-SF-8000L	8	2472	300kg	300L	G1 1/2''
CK-SF-10000L	10	3072	475kg	500L	G2''
CK-SF-12000L	12	3072	475kg	500L	G2''
CK-SF-15000L	15	3672	650kg	800L	G2''
CK-SF-20000L	20	4072	800kg	800L	G2''

Introduction
First, with strong-acid out from raw water, outlet water is relative softener water cation resin, Mg+ and Ca+ are exchanged out from raw water. Thus, water softener out from water softener is relative softer water. In this phase, Chemical reaction is 2RNa+Ca+(mg2+)=R2Ca(mg)+2Na+. The resin must be regenerated when it had adsorbed enough Ca+, Mg+, With 2%-5% strong salt water (with flow rate of 6/m/h), it exchanges out Ca+, Mg+from the resin, then whose ability of ion exchange will be recovered. In this step, the chemical reaction is: R2Ca+2Na+=2RN+Ca2+. At ast, discharging waste water.

Four key steps for the whole regeneration
1. Backwashing-to loose resin layer
2. Slow-washing for salt suction---exchange-reaction
3. Flushing-Flushing away Ca+, Mg+exchanged out from chemical reaction
4. Filling water - for next regeneration

Packaging & Shipping
Wood packing and carton packing
Chunke Portable 0.5t Salt Water Softener for Water Treatment

Company Information
Guangzhou Chunke Environmental Technology Co., Ltd. In the water treatment industry, with its
Extensive field experience and technical development capabilities, combined with the global industrial
Water treatment and new materials, new technologies developed on the basis of a series of technologically Advanced, affordable, reliable water treatment systems, industrial water treatment systems company Dedicated to product development, design and manufacturing, equipment supply, Project installation,Technical support, service, etc., and create a leading, highquality, highly efficient and robust water Treatment program, widely used in electricity, electronics, electroplating, chemical, pharmaceutical,
Food and beverage, building materials, domestic wateren and other fields

FAQ
Q. Which type of water treatment product should I purchase?
A. First know what is in your water that you want to remove specific contaminants. This is accomplished through a water analysis. Next investigate what type of systems are available that address your specific needs. There are a number of resources that you can use to make a good buying decision. Remember the overall water quality in the United States is very good, so never ever buy a product that is sold to you via scare or alarm tactics. And by all means check with several sources before you buy there are a great many over priced water treatment systems sold.
